| Cable Type | Cable Group | Impedance | Jacket O/D mm | Dielectric Material | Dielectric O/D mm | Centre Conductor Material | Centre Conductor O/D mm | Centre Conductor Stranding mm | Shielding Outer Conductor |
|---|---|---|---|---|---|---|---|---|---|
| RG178 | AA | 50 | 1.8 | PTFE | 0.84 | SCCS | 0.3 | 7/0.1 | Copper Braid |
| Image | SKU | Name | Description |
|---|---|---|---|
 | 10-006-A3-AA | BNC Straight Crimp / Crimp Plug ( 4 Part ) | BNC 50 ohm straight crimp plug, for applications up to 1GHz. Contact and crimp sleeve … |
 | 10-264-B3-AA | BNC Rear Mount Bulkhead Straight Crimp / Crimp Jack ( 5 part ) | BNC 50 ohm straight bulkhead crimp jack, rear mounted, for applications up to 2.5GHz. Contact … |
 | 13-006-A3-AA | TNC Straight Crimp / Crimp Plug ( 4 Part ) | TNC 50 ohm straight crimp plug, for applications up to 1GHz. Contact and crimp sleeve … |
 | 13-256-1-B3-AA | TNC IP68 Rear Mount Bulkhead Straight Crimp / Crimp Jack ( Bullet Contact) | TNC 50 ohm full crimp bulkhead jack is internal Sealed To IP68 Un-Mated, This rear … |
 | 13-256-A0-AA | TNC Rear Mount Bulkhead Straight Crimp / Crimp Jack ( 4 Part ) | TNC 50 ohm full crimp bulkhead jack. This rear mounted jack has a gold plated … |
 | 13-264-B3-AA | TNC Rear Mount Bulkhead Straight Crimp / Crimp Jack ( Bullet Contact ) | TNC 50 ohm full crimp bulkhead jack. This rear mounted jack has a 2 part … |
| 13-269-B3-AA | TNC Front Mount Bulkhead Straight Crimp / Crimp Jack ( Bullet Contact ) | TNC 50 ohm full crimp bulkhead jack. This front mounted jack has a gold plated … |
 | 22-007-A0-AA | FME Crimp / Crimp Plug | FME straight full crimp Plug with a metal pusher sleeve . With gold plated contact … |
 | 22-045-B3-AA | FME IP68 Crimp / Crimp Jack | FME straight full crimp Jack. Internaled Sealed and Adhesive Heatshrink to Achive IP68 Un-Mated With … |
 | 30-005-D3-AA | SMA Crimp / Crimp Plug | SMA straight full crimp plug. With gold plated contact and body. Contact and crimp sleeve … |
 | 30-054-D3-AA | SMA Crimp / Crimp Jack | SMA full crimp straight jack. Contact and body are gold plated. Contact and crimp sleeve … |
 | 30-105-D3-AA | SMA Right Angle Solder / Crimp Plug (4 Part) | SMA right angle solder crimp plug. Centre contact is soldered and the braid is crimped. … |
 | 30-256-B3-AA | SMA Rear Mount Bulkhead Crimp / Crimp Jack ( 4 part Nickel ) | SMA bulkhead mount full crimp jack, rear mounted with a single flat on the body. … |
 | 30-256-D3-AA | SMA Rear Mount Bulkhead Crimp / Crimp Jack ( 4 part ) | SMA bulkhead mount full crimp jack, rear mounted with a single flat on the body. … |
| 30-282-D3-AA | SMA Rear Mount Bulkhead Solder / Crimp Jack (5 part) | SMA bulkhead mount full crimp jack, rear mounted with a single flat on the body. … |
 | 30-290-D10-AA | SMA Rear Mount Bulkhead Crimp/Crimp Jack IP68 Sealed | SMA 50 ohm bulkhead mount full crimp jack IP68 Sealed and tested to 10m un … |
 | 30-291-D3-AA | SMA Front Mount Bulkhead Crimp/Crimp Jack IP68 Mated | SMA 50 ohm Front Mount bulkhead full crimp jack IP68 Sealed and tested to 50m … |
 | 32-005-D3-AA | SMB Straight Crimp / Crimp Plug (5 Part) | SMB 50 ohm straight full crimp plug. With gold plated contact and body. Contact and … |
 | 32-101-D3-AA | SMB Right Angle Solder / Braid Clamp Plug | SMB 50 ohm right angle solder Braid clamp plug with gold plated body and contact. … |
 | 32-254-D3-AA | SMB Rear Mount Bulkhead Crimp / Crimp Jack | SMB 50 ohm bulkhead mount full crimp jack, rear mounted with a single flat on … |
 | 32-271-D10-AA | SMB Right Angle Bulkhead Solder/Crimp Jack IP68 Hermetically Sealed | SMB 50 ohm Right Angle Rear Mounted bulkhead mount solder crimp jack IP68 Hermetically Sealed … |
 | 40-039-D3-AA | SSMC Bulkhead Solder/Crimp Jack | SSMC Bulkhead Jack(SSMC Jacks has a Male Contact)Centre Contacts and Crimp Tube are gold plated |
 | 40-105-D3-AA | SSMC Right Angle Solder/Crimp Plug | SSMC Right Angle Plug (SSMC Plugs have a Female Contact) Solder Centre Contact with Crimp … |
 | 45-005-D3-AA | MCX Straight Crimp / Crimp Plug (4 Part) | MCX 50 ohm full crimp straight with plug gold plated contact and body. Contact and … |
 | 45-105-D3-AA | MCX Right Angle Solder / Crimp Plug | MCX 50 ohm right angle plug with soldered centre contact and crimped braid. Gold plated … |
 | 47-005-D3-AA | MMCX Straight Crimp / Crimp Plug | MMCX 50 ohm full crimp straight plug. With gold plated centre contact and annealed crimp … |
 | 47-054-D3-AA | MMCX Straight Crimp / Crimp Jack | MMCX 50 ohm full crimp straight jack with gold plated centre and outer contact. Contact … |
 | 47-105-D3-AA | MMCX Right Angle Solder / Crimp Plug | MMCX 50 ohm right angle solder crimp plug. With gold plated centre contact and annealed … |
 | 56-105-Q3-AA | SMP Non Magnetic Right Angle Solder / Crimp Plug | SMP 50 ohm right angle plug with soldered centre contact and crimped braid. Non Magnetic … |
 | 56M-057-1-D3-AA | SMPM Straight Solder/Crimp Jack | SMPM Straight Solder/Crimp ( Female ) Jack SMPM are a series of blind mate connectors … |
 | 56M-057-D3-AA | SMPM Straight Solder/Crimp Jack | SMPM Straight Solder/Crimp ( Female ) Jack SMPM are a series of blind mate connectors … |
 | 67-005-B3-AA | Micro BNC Straight Crimp / Crimp Plug 50 ohm | Micro BNC 50 ohm straight crimp / crimp plug. With gold plated centre contact and … |
 | 77-400-D3-AA | Coaxial PCB Crimp Cable Termination | Straight coaxial Cable Crimp termination, for fixing of coaxial cable directly on to a PCB. … |
 | 99-027-Q3-AA | Bayonet Lock IP68 Crimp/Crimp Plug | Using the technology of a BNC and the interface of a SMA and Using a … |
 | 99-290-Q3-AA | Bayonet Lock IP68 Crimp/Crimp Bulkhead Jack | Using the technology of a BNC and the interface of a SMA and Using a … |
 | RG178 | RG178 | |
| RG196 | RG196 |
